MIXFLO MONOTUBE HEAT EXCHANGER

The Monotube Mixflo Heat Exchanger consists of two concentric corrugated tubes. The product to be thermally processed flows inside the smaller tube while service fluid flows inside the external jacket. The Monotube Mixflo Heat Exchanger is fully/wholly welded (manufactured) with expansion joint when necessary. Application range  Particularly suited for thermal exchange process of products having a medium or high viscosity even with particulates.

STANDARD FEATURES

  • Low to High Capacity
  • Stainless steel AISI 304/316 (Other kind of materials are available on request)
  • Product side Ra <0,8 µm
  • Connections DIN-CLAMP-SMS-BS-FLANGE
  • Pressure up to 10 bar  (Higher pressures are available depending on utilized connections)
  • Every exchanger is in accordance with 97/23/CE standards (PED)
